Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Ranging Principle | dToF |
| Wavelength | 905nm |
| Horizontal Field of View | 270° |
| Measurement Range | ≥10m@70%reflectivity ≥5m@10%reflectivity |
| Scan Frequency | 10Hz; 15Hz; 20Hz; 25Hz; 30Hz |
| Data Sample Rate | 22.5kHz |
| Horizontal Resolution | 0.16°(10Hz) / 0.24°(15Hz) / 0.32°(20Hz) / 0.4°(25Hz) / 0.48°(30Hz) |
| Accuracy (Typical) | ±2cm |
| Data Protocol | RS485-MODBUS |
| Digital Channels | 4 Digital Inputs, 4 Digital Outputs |
| Digital Outputs | 4 NPN (or PNP), Iout ≤ 100mA |
| Response Time | 33ms (30Hz) |
| Start Time | <15s |
| Detection Output Time | 0 ~ 1000ms |
| Detection Holding Time | 0 ~ 1000ms |
| Laser Safety | Class 1 Eye safe |
| Ambient Light Immunity | < 100 Klux |
| Rated Voltage Range | 9~36V |
| Power Consumption (Typical) | 2.5W |
| Dimension (D × W × H) | 55mm × 55mm × 51mm |
| Operating Temperature | -25°C ~ 60°C |
| Storage Temperature | -40°C ~ 75°C |
| Ingress Protection | IP67 |
-
