Technical Specifications
| Parameter | Value |
|---|---|
| Detection range under water | >5 m Indoor, NTU<0.5, 30% reflectivity, the light beam is perpendicular to the target surface |
| Blind zone | ≤ 0.1 m |
| Accuracy | < 3 cm (0.1 ~ 2m) |
| Repeatability | < 1 cm @ 1σ (0.1 ~ 2m) |
| Distance resolution | 1 mm |
| Default frame rate | Default 20 Hz |
| Ambient light resistance | 100 KLux |
| Light source | Laser |
| Central wavelength | Red |
| Field of View (FoV) | < 0.5° |
| Eye safety | Class 1 (IEC 60825-1:2014; EN 60825-1:2014+A11:2021) |
| Average power consumption | < 5V × 100mA |
| Peak current at start up | < 700mA |
| Power supply | DC 5 ± 0.2 V |
| Logical voltage | 3.3 V TTL |
| Connector | 1.0mm-4P, model is HC-1.0-4PWT |
| Operating temperature | 0 ℃ ~ +50 ℃ |
| Storage temperature | -20 ℃ ~ +70 ℃ |
| Protection level | NA |
| Typ. Dimensions | 24.0 mm × 16.0 mm × 20.4 mm |
| Typ. Weight (excluding cables) | < 5 g |
| Communication Interface | UART / I2C (Can be switched by command) |
| Baud rate | Default 115200 (Configurable) |
| Data bit | 8 |
| Stop bit | 1 |
| Parity | None |
BENEWAKE-TF-UW500_Datasheet.pdf
BENEWAKE-TF-UW500_User_Manual.pdf
-
