Technical Specifications
| Parameter | Value |
|---|---|
| Range (Indoor, no ambient light) | 0.2~350m @90% reflectivity 0.2-110m @10% reflectivity |
| Range (Outdoor @100Klux) | 0.2-300m @90% reflectivity 0.2-100m @10% reflectivity |
| Accuracy | ±10cm (within 10m), 1% (10m and further) |
| Distance resolution | 1cm |
| Frame rate | 1Hz~1000Hz adjustable (default 100Hz) |
| Repeatability | 1σ: <3cm |
| Ambient light immunity | 100Klux |
| Enclosure rating | IP67 |
| Light source | LD |
| Central wavelength | 905nm |
| Photobiological safety | Class1 (EN60825) |
| Field of View (FOV) | 0.35° |
| Supply voltage | 5V~24V |
| Average current | ≤150mA @5V, ≤80mA @12V, ≤50mA @24V |
| Power consumption | ≤1W |
| Communication interface level | LVTTL (3.3V) |
| Communication interface | UART/CAN |
| Dimension (L×W×H) | 78mm × 67mm × 40mm |
| Enclosure material | Aluminum alloy |
| Operation temperature | -25~60℃ |
| Storage temperature | -40~85℃ |
| Weight | 222g ± 3g |
| Cable length | 70cm |
BENEWAKE-TF350-Drawing.pdf
-
