Technical Specifications
| Parameter | Value |
|---|---|
| Detection range① | 3 m ~ 1200 m |
| Accuracy① | 1% @ ≤200 m |
| Repeatability① | 6 cm @ <200 m |
| Distance resolution | 10 cm |
| Frame rate | 3 Hz |
| Light source | EEL |
| Central wavelength | 905 nm |
| Field of View (FoV) | < 0.5° |
| Eye safety | Class 1 [EN60825] |
| Ambient light resistance | 100 KLux |
| Average power consumption② | < 1.1 W |
| Power supply | DC 2.7 V ~ 5.0 V |
| Data output | 3.3V TTL |
| Operating temperature | -40℃ ~ +65℃ |
| Storage temperature | -40℃ ~ +70℃ |
| Operating humidity | ≤70% |
| Dimensions | TYP. 25 × 25 × 13 mm³ |
| Weight | 11 g ± 0.5 g |
| Communication interface | UART |
| Baud rate | Default 115200 |
| Data bit | 8 |
| Stop bit | 1 |
| Parity | None |
BENEWAKE-TFA1200-L_Datasheet.pdf
-
Contact Seller:
+861368646****
Benewake presents 21 published products on Global Robot Market, giving buyers a direct way to review inquiry-ready offerings across LiDAR & Range Sensors.
This store page is intended for sourcing teams that want to compare listed products, review technical positioning, and contact the supplier for pricing, lead time, customization, or OEM and ODM discussions.
If the listed products match your project requirements, use the inquiry flow on the product page to request commercial and technical details from Benewake.
