Product Overview
The FANUC LR Mate 200iD/7L is a long-reach, compact 6-axis industrial robot designed for high-precision tasks in confined spaces. With a 911 mm horizontal reach and 7 kg payload, it offers exceptional flexibility for machine tending, pick-and-place, and assembly applications. Featuring ±0.02 mm repeatability and high-speed joint motion up to 720°/s, it integrates seamlessly with iRVision and force sensing. The slim arm design and IP67 protection enable deployment in harsh environments, while the R-30iB Plus controller supports advanced programming and safety functions. Ideal for automotive, electronics, and general manufacturing, the LR Mate 200iD/7L maximizes productivity in small-footprint cells.
Key Features
- Extended 911 mm Reach: Accesses deep into machines.
- 7 kg Payload: Handles heavier tools and parts.
- ±0.02 mm Repeatability: Precision for tight tolerances.
- IP67 Protection: Dust and water resistant.
- iRVision Ready: Integrated 2D/3D vision guidance.
- Compact Design: 190 x 190 mm footprint.
- R-30iB Plus Controller: Dual safety, DCS included.
- Force Control Option: Sensitive assembly tasks.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | LR Mate 200iD/7L |
| Axes | 6 |
| Payload | 7 kg |
| Reach | 911 mm |
| Repeatability | ±0.02 mm |
| Mounting | Floor, Ceiling, Angle, Wall |
| Controller | R-30iB Plus |
| Protection | IP67 (wrist), IP54 (body) |
| Motion Speed (J1-J6) | 260°/s / 240°/s / 320°/s / 480°/s / 480°/s / 720°/s |
Applications
- Machine Tending: CNC loading/unloading.
- Assembly: Electronics and automotive parts.
- Material Handling: Bin picking and sorting.
- Inspection: Vision-guided quality checks.
- Packaging: Case packing and palletizing.
Frequently Asked Questions
What is the maximum reach?
911 mm horizontal reach.
Can it be mounted upside down?
Yes, supports ceiling and angle mounting.
Is vision included?
iRVision is fully integrated, no external PC needed.
What is the wrist protection?
IP67 for washdown environments.
Does it support force control?
Yes, with FS-7 force sensor option.
