Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Reduction Ratio | 24 |
| Rated Voltage | 48 V |
| Rated Bus Current | 35.12 A |
| Rated Phase Current | 44.05 A |
| Rated Power | 1686 W |
| Rated Speed | 115 RPM |
| Rated Torque | 100 Nm |
| Peak Speed | 123 RPM |
| Peak Phase Current | 140 A |
| Peak Torque | 330 Nm |
| Efficiency | 75% |
| Torque Constant | 2.6 Nm/A |
| Weight | 2172~2211 g |
| Backlash | 20 Arcmin |
| Motor Size | 124x85 mm |
| Hole Diameter | 8 mm |
| Communication Mode | CAN |
| Communication Baud Rate | 1M |
| Double Encoder | Yes |
| Axial And Radial Loads | 6.76 KN |
| Bending Moment Resistance | 300 Nm |
| Cross Roller Bearing Type | 9008 |
| The Rotor Inertia Of The Motor | 477 kgmm² |
| Torque Density | 149~152 Nm/kg |
-
