Technical Specifications
| Parameter | Value |
|---|---|
| Reduction Ratio | 36 |
| Rated Voltage | 48 V |
| Rated Bus Current | 2.1 A |
| Rated Phase Current | 2.4 A |
| Rated Power | 101 W |
| Rated Speed | 207 RPM |
| Rated Torque | 3 Nm |
| Peak Speed | 220 RPM |
| Peak Phase Current | 10 A |
| Peak Torque | 12 Nm |
| Efficiency | 60% |
| Torque Constant | 1.35 Nm/A |
| Weight | 162 g |
| Backlash | 12 Arcmin |
| Motor Size | 44x44 mm |
| Communication Mode | CAN |
| Communication Baud Rate | 1M |
| Double Encoder | Yes |
| Axial And Radial Loads | 2.23 KN |
| Bending Moment Resistance | 13 Nm |
| The Rotor Inertia Of The Motor | 4.26 kgmm² |
| Torque Density | 74.1 Nm/kg |
| Pole Pair | 7 |
| Phase Resistance | 780 mΩ |
| Phase Inductance | 135 μH |
-
