Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Reduction Ratio | 100 |
| Rated Voltage | 48 V |
| Rated Bus Current | 4.3 A |
| Rated Phase Current | 5.2 A |
| Rated Power | 206.4 W |
| Rated Speed | 45 RPM |
| Rated Torque | 40 Nm |
| Peak Speed | 47 RPM |
| Peak Phase Current | 25 A |
| Peak Torque | 130 Nm |
| Efficiency | 45% |
| Torque Constant | 5.6 Nm/A |
| Weight | 906 g |
| Backlash | 10 Arcsec |
| Motor Size | 73x84 mm |
| Hole Diameter | 11 mm |
| Communication Mode | CAN |
| Communication Baud Rate | 1M |
| Double Encoder | Yes |
| Axial And Radial Loads | 2.14 KN |
| Bending Moment Resistance | 40 Nm |
| Cross Roller Bearing Type | 4005 |
| The Rotor Inertia Of The Motor | 24 kgmm² |
| Torque Density | 143.5 Nm/kg |
-
