Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | EC-A8112-P1-18 | EC-A8112-P1-18H |
|---|---|---|
| Reduction Ratio | 18 | 18 |
| Rated Voltage | 48 V | 48 V |
| Rated Bus Current | 13.3 A | 13.3 A |
| Rated Phase Current | 15.9 A | 15.9 A |
| Rated Power | 638.4 W | 638.4 W |
| Rated Speed | 155 RPM | 155 RPM |
| Rated Torque | 30 Nm | 30 Nm |
| Peak Speed | 157 RPM | 157 RPM |
| Peak Phase Current | 60 A | 60 A |
| Peak Torque | 90 Nm | 90 Nm |
| Efficiency | 78% | 78% |
| Torque Constant | 2.1 Nm/A | 2.1 Nm/A |
| Weight | 868 g | 883 g |
| Backlash | 12 Arcmin | 12 Arcmin |
| Motor Size | 105x53 mm | 105x53 mm |
| Hole Diameter | - | 5 mm |
| Communication Mode | CAN | CAN |
| Communication Baud Rate | 1M | 1M |
| Double Encoder | Yes | Yes |
| Axial And Radial Loads | 2.81 KN | 2.81 KN |
| Bending Moment Resistance | 98 Nm | 98 Nm |
| Cross Roller Bearing Type | 7005 | 7005 |
| The Rotor Inertia Of The Motor | 150 kgmm² | 98 kgmm² |
| Torque Density | 103.7 Nm/kg | 102 Nm/kg |
-
