Technical Specifications
| Parameter | Education Edition |
| Dimensions (L × W × H, standing) | 1400(H) x 535.55(W) x 252.66(D) |
| Weight (including battery) | nearly 43kg |
| Calf and thigh length | 686.5mm |
| Arm span | 1.44m |
| Total DOF | 24 |
| Fully Hollow-Joint Internal Routing | √ |
| Joint Motion Space |
lumbar joint：-230°~90° Hip joint:R-29°~+134°、P-180°~+140°、Y-90°~+230° knee joint：-30°~+137 |
| Movement Speed | ＞2m/s(Hardware Support) |
| Perception Sensor | Two depth cameras (head and waist) |
| Basic computing power | 4-core high-performance CPU |
| High-Performance Computing Module | NVIDIA Jetson Orin NX (16G) |
| Secondary development | support |
| Smart Battery (Quick-Release) | 10000mAh |
| Battery life | nearly 2 hour |
| Charging Power | 54.6V 4.5A |
| Charging speed | nearly 2 hour |
| Lighting Configuration | Eye lamp, Buttock lamp |
| Handheld Remote Control | √ |
| Touch screen | √ |
| Joint encoder | Dual Encoding |
| Joint Type | Planetary |
| Maximum Torque (Nm) | 50 |
| Peak torque density | 100 Nm/kg |
| Maximum speed (rpm) | 8400 |
| Reduction ratio | 25 |
| quanlity（kg） | 0.5 |
