Technical Specifications
| Parameter | |||
|---|---|---|---|
| Servo Model | AP-1112-C001 | AP-1812-C001 | AP-2224-C001 |
| Operating Voltage | 9-14V (typical value 12V) | 9-14V (typical value 12V) | 16-28V (typical value 24V) |
| Encoder Type | 12-bit magnetic coding | 12-bit magnetic coding | 12-bit magnetic coding |
| Output Shaft | 15T | 15T | 15T |
| Kt Constant | 12.36kg.cm/A | 20.22kg.cm/A | 33.8kg.cm/A |
| Quiescent Current | 50mA | 50mA | 30mA |
| No-load Current | 500mA | 400mA | 300mA |
| Gear Type | High-precision steel teeth (reduction ratio 1:290) | High-precision steel teeth (reduction ratio 1:290) | High-precision steel teeth (reduction ratio 1:290) |
| No-load Speed | 0.227sec/60degree 44RPM@12V | 0.25sec/60degree 40RPM@12V | 0.222sec/60degree 45RPM@12V |
| Resolution of Position Sensor | 0.10°(180°/1800) | 0.10°(180°/1800) | 0.10°(180°/1800) |
| Rated Load | 35kg.cm@12V | 60kg.cm@12V | 70kg.cm@12V |
| Rated Current | 2900mA | 2900mA | 2000mA |
| Locked Rotor Torque | 110kg.cm@12V | 180kg.cm@12V | 220kg.cm@24V |
| Rotation Angle | 180°(600US~2400US) | 180°(600US~2400US) | 180°(600US~2400US) |
| Institutional Limit Angle | 200° | 200° | 200° |
-
