Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Model | SM-2924-C001 |
| Product Name | 24V 12kg Modbus-RTU Servo |
| Storage Temperature Range | -30°C~80°C |
| Operating Temperature Range | -15°C~80°C |
| Size | A: 40mm B: 28mm C: 42.3mm |
| Weight | 102g |
| Gear Type | High-precision all-metal gear |
| Limit Angle | No Limiter |
| High Torque | 12Kg.cm@24V |
| Wide Operating Voltage | 12-24V |
| High Resolution | 12-bit Encoder (360°/4096, 0.088°) |
| Servo Control Mode | Rotation Range 0-360° & Multi-turn Arbitrary Angle |
| Duplex Asynchronous | Modbus-RTU Communication Protocol |
| Serial Bus Connection | 254 ID Addresses Optional |
| Baud Rate | 9600-256000 |
| Power Supply Voltage | 24 VDC |
| Continuous Current | 0.8 A |
| Maximum Axial Load | 3N |
| Maximum Radial Load | 10N |
| Operating Temperature | 35°C |
| Quiescent Current | 35mA |
| No-load Current | 130mA |
| Stall Current | 1200mA |
| PWM Frequency | 16KHZ |
| Position Resolution | 0.088° |
| Stall Torque | 24kg.cm@24V |
| Maximum Speed | 110RPM |
-
