Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value | Value | Value | Value |
|---|---|---|---|---|
| Model | HBD-08 | HBD-08 | HBF-08 | HBF-08 |
| Reduction Ratio | 30 | 50 | 80 | 100 |
| Weight (kg) | 0.06 | 0.06 | 0.06 | 0.06 |
| Rated Torque at 2000 r/min (Nm) | 1.0 | 1.95 | 2.5 | 2.85 |
| Rated Torque at 2000 r/min (Kgf·m) | 0.11 | 0.20 | 0.26 | 0.29 |
| Permissible Peak Torque (Start/Stop) (Nm) | 2.1 | 3.95 | 4.8 | 5.5 |
| Permissible Peak Torque (Start/Stop) (Kgf·m) | 0.21 | 0.395 | 0.48 | 0.55 |
| Allowable Average Load Torque (Nm) | 1.65 | 2.75 | 3.50 | 3.95 |
| Allowable Average Load Torque (Kgf·m) | 0.17 | 0.28 | 0.36 | 0.4 |
| Instantaneous Permissible Maximum Torque (Nm) | 3.95 | 7.95 | 9 | 10.8 |
| Instantaneous Permissible Maximum Torque (Kgf·m) | 0.4 | 0.8 | 0.91 | 1.09 |
| Permissible Max Input Speed (r/min) | 8500 | 8500 | 8500 | 8500 |
| Permissible Average Input Speed (r/min) | 3500 | 3500 | 3500 | 3500 |
| Moment of Inertia (1/4GD²) (kg·cm²) | 3.2×10³ 3.0×10³ |
3.2×10³ 3.0×10³ |
3.2×10³ 3.0×10³ |
3.2×10³ 3.0×10³ |
| Backlash (Arc sec) | ≤20 | ≤20 | ≤20 | ≤20 |
| Parameter | Value | Value | Value | Value |
|---|---|---|---|---|
| Model | HBD-11 | HBD-11 | HBF-11 | HBF-11 |
| Reduction Ratio | 30 | 50 | 80 | 100 |
| Weight (kg) | 0.13 | 0.13 | 0.13 | 0.13 |
| Rated Torque at 2000 r/min (Nm) | 2.6 | 4.2 | 5.0 | 6.0 |
| Rated Torque at 2000 r/min (Kgf·m) | 0.27 | 0.43 | 0.51 | 0.61 |
| Permissible Peak Torque (Start/Stop) (Nm) | 5.5 | 10 | 10.5 | 13.2 |
| Permissible Peak Torque (Start/Stop) (Kgf·m) | 0.55 | 1.0 | 1.1 | 1.3 |
| Allowable Average Load Torque (Nm) | 4.0 | 6.6 | 8.6 | 10.5 |
| Allowable Average Load Torque (Kgf·m) | 0.41 | 0.67 | 0.87 | 1.20 |
| Instantaneous Permissible Maximum Torque (Nm) | 10.2 | 20 | 24 | 30 |
| Instantaneous Permissible Maximum Torque (Kgf·m) | 1.02 | 2 | 2.4 | 3 |
| Permissible Max Input Speed (r/min) | 8500 | 8500 | 8500 | 8500 |
| Permissible Average Input Speed (r/min) | 3500 | 3500 | 3500 | 3500 |
| Moment of Inertia (1/4GD²) (kg·cm²) | 1.4×10² 1.2×10² |
1.4×10² 1.2×10² |
1.4×10² 1.2×10² |
1.4×10² 1.2×10² |
| Backlash (Arc sec) | ≤20 | ≤20 | ≤20 | ≤20 |
| Parameter | Value | Value | Value | Value |
|---|---|---|---|---|
| Model | HBD-14 | HBD-14 | HBF-14 | HBF-14 |
| Reduction Ratio | 30 | 50 | 80 | 100 |
| Weight (kg) | 0.31 | 0.31 | 0.31 | 0.31 |
| Rated Torque at 2000 r/min (Nm) | 2.6 | 4.2 | 5 | 6 |
| Rated Torque at 2000 r/min (Kgf·m) | 0.27 | 0.43 | 0.51 | 0.61 |
| Permissible Peak Torque (Start/Stop) (Nm) | 5.5 | 10 | 10.5 | 13.2 |
| Permissible Peak Torque (Start/Stop) (Kgf·m) | 0.55 | 1 | 1.1 | 1.3 |
| Allowable Average Load Torque (Nm) | 4 | 6.6 | 8.6 | 10.5 |
| Allowable Average Load Torque (Kgf·m) | 0.41 | 0.67 | 0.87 | 1.2 |
| Instantaneous Permissible Maximum Torque (Nm) | 10.2 | 20 | 24 | 30 |
| Instantaneous Permissible Maximum Torque (Kgf·m) | 1.02 | 2 | 2.4 | 3 |
| Permissible Max Input Speed (r/min) | 8500 | 8500 | 8500 | 8500 |
| Permissible Average Input Speed (r/min) | 3500 | 3500 | 3500 | 3500 |
| Moment of Inertia (1/4GD²) (kgms²) | 1.4×10² 1.2×10² |
1.4×10² 1.2×10² |
1.4×10² 1.2×10² |
1.4×10² 1.2×10² |
| Backlash (Arc sec) | ≤20 | ≤20 | ≤20 | ≤20 |
| Parameter | Value | Value | Value | Value |
|---|---|---|---|---|
| Model | HBD-17 | HBD-17 | HBF-17 | HBF-17 |
| Reduction Ratio | 30 | 50 | 80 | 100 |
| Weight (kg) | 0.41 | 0.41 | 0.41 | 0.41 |
| Rated Torque at 2000 r/min (Nm) | 6.8 | 11 | 14 | 16 |
| Rated Torque at 2000 r/min (Kgf·m) | 0.68 | 1.1 | 0.14 | 1.6 |
| Permissible Peak Torque (Start/Stop) (Nm) | 12 | 23 | 33 | 37 |
| Permissible Peak Torque (Start/Stop) (Kgf·m) | 1.2 | 2.3 | 3.3 | 3.8 |
| Allowable Average Load Torque (Nm) | 9.3 | 18 | 25 | 27 |
| Allowable Average Load Torque (Kgf·m) | 0.93 | 1.9 | 2.5 | 2.8 |
| Instantaneous Permissible Maximum Torque (Nm) | 27 | 48 | 71 | 71 |
| Instantaneous Permissible Maximum Torque (Kgf·m) | 2.7 | 4.9 | 0.71 | 0.71 |
| Permissible Max Input Speed (r/min) | 7300 | 7300 | 7300 | 7300 |
| Permissible Average Input Speed (r/min) | 3500 | 3500 | 3500 | 3500 |
| Moment of Inertia (×10² km²) | 0.054 | 0.054 | 0.054 | 0.054 |
| Moment of Inertia (×10⁴ kgf·m·s²) | 0.055 | 0.055 | 0.055 | 0.055 |
| Backlash (Arc sec) | ≤20 | ≤20 | ≤20 | ≤20 |
| Parameter | Value | Value | Value | Value |
|---|---|---|---|---|
| Model | HBD-20 | HBD-20 | HBF-20 | HBF-20 |
| Reduction Ratio | 30 | 50 | 80 | 100 |
| Weight (kg) | 0.52 | 0.52 | 0.52 | 0.52 |
| Rated Torque at 2000 r/min (Nm) | 9 | 17 | 24 | 28 |
| Rated Torque at 2000 r/min (Kgf·m) | 0.9 | 1.7 | 2.4 | 2.9 |
| Permissible Peak Torque (Start/Stop) (Nm) | 21 | 39 | 51 | 57 |
| Permissible Peak Torque (Start/Stop) (Kgf·m) | 2.1 | 4.0 | 5.1 | 5.8 |
| Allowable Average Load Torque (Nm) | 15 | 24 | 32 | 34 |
| Allowable Average Load Torque (Kgf·m) | 1.5 | 2.4 | 3.2 | 3.5 |
| Instantaneous Permissible Maximum Torque (Nm) | 36 | 69 | 88 | 95 |
| Instantaneous Permissible Maximum Torque (Kgf·m) | 3.6 | 7.0 | 8.8 | 10 |
| Permissible Max Input Speed (r/min) | 6500 | 6500 | 6500 | 6500 |
| Permissible Average Input Speed (r/min) | 3500 | 3500 | 3500 | 3500 |
| Moment of Inertia (×10²km²) | 0.09 | 0.09 | 0.09 | 0.09 |
| Moment of Inertia (×10⁴ kgf·m·s²) | 0.092 | 0.092 | 0.092 | 0.092 |
| Backlash (Arc sec) | ≤20 | ≤20 | ≤20 | ≤20 |
| Parameter | Value | Value |
|---|---|---|
| Model | HBD-25 | HBF-25 |
| Reduction Ratio | 50 | 100 |
| Weight (kg) | 0.95 | 0.95 |
| Rated Torque at 2000 r/min (Nm) | 27 | 47 |
| Rated Torque at 2000 r/min (Kgf·m) | 2.8 | 4.8 |
| Permissible Peak Torque (Start/Stop) (Nm) | 69 | 110 |
| Permissible Peak Torque (Start/Stop) (Kgf·m) | 7.0 | 11 |
| Allowable Average Load Torque (Nm) | 38 | 75 |
| Allowable Average Load Torque (Kgf·m) | 3.9 | 7.6 |
| Instantaneous Permissible Maximum Torque (Nm) | 127 | 184 |
| Instantaneous Permissible Maximum Torque (Kgf·m) | 13 | 19 |
| Permissible Max Input Speed (r/min) | 5600 | 5600 |
| Permissible Average Input Speed (r/min) | 3500 | 3500 |
| Moment of Inertia (×10⁴ kg·cm²) | 0.282 | 0.282 |
| Moment of Inertia (×10⁵ kgf·m·s²) | 0.288 | 0.288 |
| Backlash (Arc sec) | ≤20 | ≤20 |
| Parameter | Value | Value |
|---|---|---|
| Model | HBD-32 | HBF-32 |
| Reduction Ratio | 50 | 100 |
| Weight (kg) | 2 | 2 |
| Rated Torque at 2000 r/min (Nm) | 53 | 96 |
| Rated Torque at 2000 r/min (Kgf·m) | 5.4 | 10 |
| Permissible Peak Torque (Start/Stop) (Nm) | 151 | 233 |
| Permissible Peak Torque (Start/Stop) (Kgf·m) | 15.0 | 24 |
| Allowable Average Load Torque (Nm) | 75 | 151 |
| Allowable Average Load Torque (Kgf·m) | 7.6 | 15 |
| Instantaneous Permissible Maximum Torque (Nm) | 268 | 420 |
| Instantaneous Permissible Maximum Torque (Kgf·m) | 27 | 43 |
| Permissible Max Input Speed (r/min) | 4800 | 4800 |
| Permissible Average Input Speed (r/min) | 3500 | 3500 |
| Moment of Inertia (×10⁴ kg·cm²) | 1.09 | 1.09 |
| Moment of Inertia (×10⁴ kgf·m·s²) | 1.11 | 1.11 |
| Backlash (Arc sec) | ≤20 | ≤20 |
-
