Technical Specifications
| Parameter | Value |
|---|---|
| Reducer Standalone Speed Ratio (R₁) | 36.75 |
| Bending Moment Stiffness | 2813 Nm/arc.min. (287 kgf-m/arc.min.) |
| Permissible Bending Moment | 2450 Nm (250 kgf-m) |
| Max. Momentary Permissible Bending Moment | 4900 Nm (500 kgf-m) |
| Permissible Max. Output Speed | 40 r/min |
| Permissible Torque for Start/Stop | 2450 Nm (250 kgf-m) |
| Max. Momentary Permissible Torque | 3430 Nm (350 kgf-m) |
| Lost Motion (MAX) | 1′ Arc.min. |
| Torsional Stiffness | 510 Nm/arc.min. (52 kgf-m/arc.min.) |
| Moment of Inertia I (Reducer Standalone) | 0.475 × 10⁻³ Kg-m² |
| Moment of Inertia I (Standard Center Gear) | 0.953 × 10⁻² Kg-m² |
| Weight | 19.5 Kg |
| Output Speed | Output Torque | Input Power |
|---|---|---|
| 5 r/min | 1362 Nm (139 kgf-m) | 0.95 kW |
| 10 r/min | 1107 Nm (113 kgf-m) | 1.55 kW |
| 15 r/min | 980 Nm (100 kgf-m) | 2.05 kW |
| 20 r/min | 899 Nm (91.7 kgf-m) | 2.51 kW |
| 25 r/min | 841 Nm (85.8 kgf-m) | 2.94 kW |
| 30 r/min | 796 Nm (81.2 kgf-m) | 3.33 kW |
| 40 r/min | 730 Nm (74.5 kgf-m) | 4.08 kW |
| 50 r/min | - | - |
| 60 r/min | - | - |
-
