Technical Specifications
| Parameter | Value |
|---|---|
| Reducer Standalone Speed Ratio (R₁) | 36.57 (1390/38) |
| Bending Moment Stiffness | 1068 (109) Nm/arc.min. (kgf-m/arc.min.) |
| Permissible Bending Moment | 980 (100) Nm (kgf-m) |
| Max. Momentary Permissible Bending Moment | 1960 (200) Nm (kgf-m) |
| Permissible Max. Output Speed | 60 r/min |
| Permissible Torque for Start/Stop | 662 (67.5) Nm (kgf-m) |
| Max. Momentary Permissible Torque | 1323 (135) Nm (kgf-m) |
| Lost Motion (MAX) | 1 Arc.min. |
| Torsional Stiffness | 147 (15) Nm/arc.min. (kgf-m/arc.min.) |
| Moment of Inertia I (Reducer Standalone) | 0.550 × 10-4 Kg-m² |
| Moment of Inertia I (Standard Center Gear) | 0.563 × 10-3 Kg-m² |
| Weight | 8.5 Kg |
| Output Speed | Output Torque | Input Power |
|---|---|---|
| 5 r/min | 368 (37.5) Nm (kgf-m) | 0.26 kW |
| 10 r/min | 299 (30.5) Nm (kgf-m) | 0.42 kW |
| 15 r/min | 265 (27) Nm (kgf-m) | 0.55 kW |
| 20 r/min | 243 (24.8) Nm (kgf-m) | 0.68 kW |
| 25 r/min | 227 (23.2) Nm (kgf-m) | 0.79 kW |
| 30 r/min | 215 (21.9) Nm (kgf-m) | 0.90 kW |
| 40 r/min | 197 (20.1) Nm (kgf-m) | 1.10 kW |
| 50 r/min | 184 (18.8) Nm (kgf-m) | 1.29 kW |
| 60 r/min | 174 (17.8) Nm (kgf-m) | 1.46 kW |
-
