Technical Specifications
| Parameter | Value |
|---|---|
| Reducer Standalone Speed Ratio (R₁) | 34.86 (1499/43) |
| Bending Moment Stiffness | 9800 Nm/arc.min. (1000 kgf-m/arc.min.) |
| Permissible Bending Moment | 8820 Nm (900 kgf-m) |
| Max. Momentary Permissible Bending Moment | 17640 Nm (1800 kgf-m) |
| Permissible Max. Output Speed | 30 r/min |
| Permissible Torque for Start/Stop | 4900 Nm (500 kgf-m) |
| Max. Momentary Permissible Torque | 9800 Nm (1000 kgf-m) |
| Lost Motion (MAX) | 1′ Arc.min. |
| Torsional Stiffness | 980 Nm/arc.min. (100 kgf-m/arc.min.) |
| Moment of Inertia I (Reducer Standalone) | 1.39×10⁻³ Kg-m² |
| Moment of Inertia I (Standard Center Gear) | 1.94×10⁻² Kg-m² |
| Weight | 55.6 Kg |
| Output Speed | Output Torque | Input Power |
|---|---|---|
| 5 r/min | 2724 Nm (278 kgf-m) | 1.90 kW |
| 10 r/min | 2215 Nm (226 kgf-m) | 3.09 kW |
| 15 r/min | 1961 Nm (200 kgf-m) | 4.11 kW |
| 20 r/min | 1803 Nm (184 kgf-m) | 5.04 kW |
| 25 r/min | 1686 Nm (172 kgf-m) | 5.88 kW |
| 30 r/min | 1597 Nm (163 kgf-m) | 6.69 kW |
-
