Technical Specifications
| Parameter | Value |
|---|---|
| Reducer Standalone Speed Ratio (R₂) | 210 |
| Bending Moment Stiffness | 12740 Nm/arc.min. (1300 kgf-m/arc.min.) |
| Permissible Bending Moment | 20580 Nm (2100 kgf-m) |
| Max. Momentary Permissible Bending Moment | 39200 Nm (4000 kgf-m) |
| Permissible Max. Output Speed | 25 r/min |
| Permissible Torque for Start/Stop | 7840 Nm (800 kgf-m) |
| Max. Momentary Permissible Torque | 15680 Nm (1600 kgf-m) |
| Lost Motion (MAX) | 1' Arc.min. |
| Torsional Stiffness | 1960 Nm/arc.min. (200 kgf-m/arc.min.) |
| Moment of Inertia I (Reducer Standalone) | 0.459×10-3 Kg-m² |
| Moment of Inertia I (Standard Center Gear) | 0.636×10-3 Kg-m² |
| Weight | 92.1 Kg |
| Output Speed (r/min) | Output Torque (Nm (kgf-m)) | Input Power (kW) |
|---|---|---|
| 5 r/min | 4361 Nm (445 kgf-m) | 3.04 kW |
| 10 r/min | 3538 Nm (361 kgf-m) | 4.94 kW |
| 15 r/min | 3136 Nm (320 kgf-m) | 6.57 kW |
| 20 r/min | 2881 Nm (294 kgf-m) | 8.05 kW |
| 25 r/min | 2690 Nm (275 kgf-m) | 9.41 kW |
-
Contact Seller:
+861368646****
Qinchuan presents 18 published products on Global Robot Market, giving buyers a direct way to review inquiry-ready offerings across Precision Reducers.
This store page is intended for sourcing teams that want to compare listed products, review technical positioning, and contact the supplier for pricing, lead time, customization, or OEM and ODM discussions.
If the listed products match your project requirements, use the inquiry flow on the product page to request commercial and technical details from Qinchuan.
