Technical Specifications
| Parameter | Value |
|---|---|
| Reducer Standalone Speed Ratio (R₁) | 32.54 (1985/61) |
| Bending Moment Stiffness | 1960 Nm/arc.min. (200 kgf-m/arc.min.) |
| Permissible Bending Moment | 1764 Nm (180 kgf-m) |
| Max. Momentary Permissible Bending Moment | 3528 Nm (360 kgf-m) |
| Permissible Max. Output Speed | 50 r/min |
| Permissible Torque for Start/Stop | 1225 Nm (125 kgf-m) |
| Max. Momentary Permissible Torque | 2450 Nm (250 kgf-m) |
| Lost Motion (MAX) | 1′ Arc.min. |
| Torsional Stiffness | 255 Nm/arc.min. (26 kgf-m/arc.min.) |
| Moment of Inertia I (Reducer Standalone) | 1.82×10⁻⁴ Kg-m² |
| Moment of Inertia I (Standard Center Gear) | 0.363×10⁻³ Kg-m² |
| Weight | 14.6 Kg |
| Output Speed | Output Torque | Input Power |
|---|---|---|
| 5 r/min | 681 Nm (69.5 kgf-m) | 0.48 kW |
| 10 r/min | 554 Nm (56.5 kgf-m) | 0.77 kW |
| 15 r/min | 490 Nm (50 kgf-m) | 1.03 kW |
| 20 r/min | 450 Nm (45.9 kgf-m) | 1.26 kW |
| 25 r/min | 420 Nm (42.9 kgf-m) | 1.47 kW |
| 30 r/min | 398 Nm (40.6 kgf-m) | 1.67 kW |
| 40 r/min | 366 Nm (37.3 kgf-m) | 2.04 kW |
| 50 r/min | 341 Nm (34.8 kgf-m) | 2.38 kW |
| 60 r/min | - | - |
-
