Technical Specifications
| Parameter | Value |
|---|---|
| Reducer Standalone Speed Ratio (R₁) | 200.33 / 250.6 |
| Bending Moment Stiffness | 12700 Nm/arc.min. (1296 kgf-m/arc.min.) |
| Permissible Bending Moment | 15000 Nm (1530 kgf-m) |
| Max. Momentary Permissible Bending Moment | 30000 Nm (3061 kgf-m) |
| Permissible Torque for Start/Stop | 17150 Nm (1750 kgf-m) |
| Max. Momentary Permissible Torque | 34300 Nm (3500 kgf-m) |
| Angular Transmission Error (MAX) | 1′ Arc.min. |
| Backlash (MAX) | 1′ Arc.min. |
| Lost Motion (MAX) | 1′ Arc.min. |
| Torsional Stiffness | 2120 Nm/arc.min. (216 kgf-m/arc.min.) |
| Permissible Axial Thrust | 44000 N (4489 kgf) |
| Output Speed | Output Torque | Input Power |
|---|---|---|
| 15 r/min | 6860(700) Nm(kgf-m) | 14.4 kW |
-
Contact Seller:
+861368646****
Qinchuan presents 18 published products on Global Robot Market, giving buyers a direct way to review inquiry-ready offerings across Precision Reducers.
This store page is intended for sourcing teams that want to compare listed products, review technical positioning, and contact the supplier for pricing, lead time, customization, or OEM and ODM discussions.
If the listed products match your project requirements, use the inquiry flow on the product page to request commercial and technical details from Qinchuan.
