Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Sensor | SONY 3.2MP IMX900 RGGB |
| ISP | / |
| Image Size | 1/3.1 inch CMOS |
| Exposure mode | Global shutter |
| Output Pixels | 2064H*1552V |
| Frame rate | 30fps |
| Pixel Size | 2.25um*2.25um |
| HDR Support | Yes |
| Output data | MIPI/RAW12 |
| Power Supply | 3.3V |
| Current | <350mA@3.3VDC |
| Camera interface | FPC |
| Connector | FH67-30S-0.5SV |
| Operating temp. | -30 to +75℃ |
| Performance temp. | -10 to +60℃ |
| Storage temp. | -40 to +85℃ |
| Dimensions | W: 30mm, L:35mm, H:19.4mm |
| Weight | <50g |
SENSING-SG3-IMX900C-MIPI-Drawing.pdf
SENSING-SG3-IMX900C-MIPI-Datasheet.pdf
-
Contact Seller:
+861368646****
SENSING presents 32 published products on Global Robot Market, giving buyers a direct way to review inquiry-ready offerings across Industrial Cameras.
This store page is intended for sourcing teams that want to compare listed products, review technical positioning, and contact the supplier for pricing, lead time, customization, or OEM and ODM discussions.
If the listed products match your project requirements, use the inquiry flow on the product page to request commercial and technical details from SENSING.
