Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Nominal voltage | 12V |
| Voltage range | 10~28V |
| Nominal current | 0.4A |
| Nominal power | 9.6W |
| Nominal torque | 0.02N.M |
| Nominal speed | 800rpm |
| No-load max speed |
6000rpm |
| Peak torque | 0.05N.m |
| Peak current | 1.9A |
| Speed constant |
500rpm/v |
| Torque constant | 0.023N.M/A |
| Number of pole pairs | 7Pairs |
| Phase resistance | 1.7Ω |
| Phase inductance | 0.24Mh |
| Rotor inertial | 21gcm^2 |
| Communication | RS485 / CAN |
| Encoder type |
Single-turn absolute |
| Resolution | 14bit |
| Motor weight | 35g |
| Working temperature | -20~80℃ |
DD3006_installation_drawing.pdf
SteadyWin_DD3006_motor.stp
-
