Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value |
|---|---|
| Winding Type | Y |
| Testing Voltage | 24V |
| Rated Power |
410W |
| Nominal Torque | 10.2N.M |
| Stall Torque |
24.78N.M |
| Nominal Speed after Reducer | 288RPM |
| Max Speed after Reducer | 390RPM |
| Nominal Current | 17.1A |
| Stall Current | >60A |
| Phase to Phase Resistance | 0.06Ω |
| Phase to Phase Inductance |
0.03mH |
| Speed Constant | 16.25rpm/v |
| Torque Constant | 0.6N.M/A |
| Number of pole pairs | 21Pairs |
| Gear Rate | 1:8 |
| Gear Type |
Planetary |
| Reducer Gear Material | STEEL |
| Reducer Gear Backlash | 15arcmin |
| Motor Weight without Driver | 327.3g |
| Size without Driver | Ø87*25.5mm |
| Max Axial Load | 225N |
| Max Radial Load | 900N |
| Protection Grade | IP54 |
| Working Temperature | -20~65℃ |
GWK8108-8_nstallation_drawing.pdf
SteadyWin_GWK8108-8_motor.stp
-
Contact Seller:
+861368646****
SteadyWin presents 26 published products on Global Robot Market, giving buyers a direct way to review inquiry-ready offerings across Servo Motors.
This store page is intended for sourcing teams that want to compare listed products, review technical positioning, and contact the supplier for pricing, lead time, customization, or OEM and ODM discussions.
If the listed products match your project requirements, use the inquiry flow on the product page to request commercial and technical details from SteadyWin.
