Technical Specifications
| Parameter | Value |
|---|---|
| Power Consumption | <19W |
| Body Weight | 870g (1.9 lbs) without tripod |
| Dimensions | 130mm × 90mm × 77mm (5.1×3.5×3.0 in) |
| Housing Material | Aerospace-grade Aluminum Alloy |
| Data Interface | USB 3.0 |
| Internal Storage | 512GB |
| GPS Module | Supported |
| WiFi | 802.11 a/b/g/n/ac/ax 2.4GHz: 2412-2472MHz 5GHz: 5180-5240MHz 5GHz: 5745-5825MHz |
| Bluetooth | 5.2 |
| Wireless Range | 20m (65.6 ft) |
| Battery Type | Removable Li-ion |
| Battery Capacity | 23.04Wh |
| Operating Time | 60 minutes (continuous scanning) |
| Charging Time (25°C/77°F) | 0-90%: 70 minutes 0-100%: 90 minutes |
| Operating Temperature | -20°C to 45°C (-4°F to 113°F) (indirect sunlight only) |
| Charging Temperature | 5-30°C (41-86°F) |
| Laser Classification | Class 1 / 940nm |
| Scanning Range | 0.1m-30m (4 in-98 ft) @ 10% reflectivity 60m (197 ft) @ 90% reflectivity |
| Field of View | 180° azimuth × 180° elevation |
| Point Rate | 856,000 points/second |
| Camera Configuration | 4-camera array 2× Fisheye, 2× Front |
| Image Resolution | 4000 × 3000 px |
| Sensor Size | 1/2" CMOS |
| Shutter Type | Rolling Shutter |
| Fisheye Camera FOV | 200° × 200° |
| Front Camera FOV | 100° × 85° |
| Input | 100-240V, 50-60Hz, 1.5A, 80VA |
| Output | 20V, 2.0A |
| Rated Power | PD Protocol, >25W Standard: USB-C 45W single port Dual port: 25W + 20W |
| Backpack with Protective Insert | Included |
| Extension Pole (2m / 6.6 ft) | Optional |
| External Storage (512GB/1TB SSD) | Optional |
-
