Application Scenarios
Humanoid Robots
Robotic Arms
Exoskeletons
Quadruped Robots
AGV Vehicles
ARU Robots
Technical Specifications
| Parameter | Value | Value | Value |
|---|---|---|---|
| Model | MINIFJ8 | MINIFJ8 | MINIFJ8 |
| Reduction Ratio | 30 | 50 | 100 |
| Weight (kg) | 0.11 | 0.11 | 0.11 |
| Rated Torque at 2000 r/min (Nm) | 0.9 | 1.8 | 2.4 |
| Rated Torque at 2000 r/min (Kgf·m) | 0.09 | 0.18 | 0.24 |
| Permissible Peak Torque (Start/Stop) (Nm) | 1.8 | 3.3 | 4.8 |
| Permissible Peak Torque (Start/Stop) (Kgf·m) | 0.18 | 0.34 | 0.49 |
| Allowable Average Load Torque (Nm) | 1.4 | 2.3 | 3.3 |
| Allowable Average Load Torque (Kgf·m) | 0.14 | 0.23 | 0.34 |
| Instantaneous Permissible Maximum Torque (Nm) | 3.3 | 6.6 | 9 |
| Instantaneous Permissible Maximum Torque (Kgf·m) | 0.34 | 0.67 | 0.92 |
| Permissible Max Input Speed (Grease Lubrication) (r/min) | 8500 | 8500 | 8500 |
| Permissible Average Input Speed (Grease Lubrication) (r/min) | 3500 | 3500 | 3500 |
| Moment of Inertia (1/4GD²) (kg·cm²) |
3.2×10³
3.0×10³ |
3.2×10³
3.0×10³ |
3.2×10³
3.0×10³ |
| Backlash (Arc sec) | ≤20 | ≤20 | ≤20 |
| Parameter | Value | Value | Value | Value |
|---|---|---|---|---|
| Model | MINIFJ11 | MINIFJ11 | MINIFJ11 | MINIFJ11 |
| Reduction Ratio | 30 | 50 | 80 | 100 |
| Weight (kg) | 0.21 | 0.21 | 0.21 | 0.21 |
| Rated Torque at 2000 r/min (Nm) | 2.2 | 3.5 | 5 | 5 |
| Rated Torque at 2000 r/min (Kgf·m) | 0.22 | 0.36 | 0.51 | 0.51 |
| Permissible Peak Torque (Start/Stop) (Nm) | 4.5 | 8.3 | 11 | 11 |
| Permissible Peak Torque (Start/Stop) (Kgf·m) | 0.46 | 0.85 | 1.12 | 1.12 |
| Allowable Average Load Torque (Nm) | 3.4 | 5.5 | 8.9 | 8.9 |
| Allowable Average Load Torque (Kgf·m) | 0.35 | 0.56 | 0.91 | 0.91 |
| Instantaneous Permissible Maximum Torque (Nm) | 8.5 | 17 | 25 | 25 |
| Instantaneous Permissible Maximum Torque (Kgf·m) | 0.87 | 1.73 | 2.55 | 2.55 |
| Permissible Max Input Speed (Grease Lubrication) (r/min) | 8500 | 8500 | 8500 | 8500 |
| Permissible Average Input Speed (Grease Lubrication) (r/min) | 3500 | 3500 | 3500 | 3500 |
| Moment of Inertia (1/4GD²) (kg·cm²) |
1.4×10⁻²
1.2×10⁻² |
1.4×10⁻²
1.2×10⁻² |
1.4×10⁻²
1.2×10⁻² |
1.4×10⁻²
1.2×10⁻² |
| Backlash (Arc sec) | ≤20 | ≤20 | ≤20 | ≤20 |
-
Contact Seller:
+861368646****
PY TECHNOLOGY presents 12 published products on Global Robot Market, giving buyers a direct way to review inquiry-ready offerings across 6-Axis Articulated and Precision Reducers.
This store page is intended for sourcing teams that want to compare listed products, review technical positioning, and contact the supplier for pricing, lead time, customization, or OEM and ODM discussions.
If the listed products match your project requirements, use the inquiry flow on the product page to request commercial and technical details from PY TECHNOLOGY.
